• Ultra High Sensitivity to all metals
• Enhanced product throughput rate
• Validation Solutions Available: Calibration Standards; Validation Manuals; Compliance Tools; Comprehensive Service & Support; On-line production data validation
• AISI 316L stainless steel construction
• Control Power Box available according to UL 508A and CSA-C22.2 No. 14-05
• 500 product data memories, selectable by local programming or network software
• 10.000 storable events
• High-definition graphic display
• Local programming: 16 keys, 3 with double function
• Quick Access key for fast programming of user parameters
• ATEX21 version (available on demand)

The ejection system is fitted with an innovative deflector that features quick response, precise ejection of the contaminated product and high production flow rate.

• Interfaces
• MD Scope
• Software
• Validation Manual
• Infeed

Ethernet module required for the network connection of several metal detectors or for the connection of one or more metal detectors over long distances.

Wi-Fi module required for the network connection of several metal detectors or for the connection of one or more metal detectors over long distances.

MDSCOPE is a software package specifically developed by CEIA in order to allow easy and complete testing of the functioning of a Metal Detector – without the use of special instrumentation – both during the setting up phase and on the occasion of periodic tests. Using a personal computer, MDSCOPE allows adjustment and monitoring of the Metal Detector, as well as the storage and printing of the data gathered.

THS Production plus software for statistical and operational management of networked THS systems.

Validation Manual according to CGMP, GAMP (including Title 21 CFR Part 11) – Customized for each Metal Detection Systems THS/PH21.

Set from 2 to 5 pieces to easily feed up the Metal Detector.
